Application: height adjustment and width adjustment for Lift table, office furniture, adjustable working plane,
conveyor technique
Technical data: lift: 350 mm (special stroke on request) speed: 7 mm/sec.
Max. weight by central pressure: 1500N/Liftsäule
Max. power- on time 20% (5 Min bei 20° C)
24V DC-motor IP-30
2 m motor cable with plug for control
|
